Grumman TBF/TBM Avenger
Grumman TBF/TBM Avenger
Grumman TBF/TBM Avenger
Grumman TBF/TBM Avenger
Grumman TBF/TBM Avenger
Grumman TBF/TBM Avenger

Grumman TBF/TBM Avenger

Snapshot
Nickname:
Avenger; (AKA) Chuff; Turkey; Pregnant Beast
Number Built:
9,839
Make:
Grumman Aircraft Company * Eastern Aircraft Division of General Motors
Mission:
Torpedo Bomber
Location:
ハンガー79
Background

Though its introduction to combat at the Battle of Midway was not a promising start (five of the six Grumman TBF-1 Avengers assigned to Torpedo Squadron (VT) 8 were shot down, and the lone survivor was heavily damaged), the TBF became the Navy’s standard torpedo bomber throughout the war. It served in other roles as well. This included glide bombing in close air support, reconnaissance, and light transport. In all, 9,836 Avengers were built, 7,546 of which were turned out by General Motors Eastern Aircraft Division and designated TBMs.

Ordered by the Navy in April 1940, the XTBF-1 was Grumman’s first attempt to build a torpedo bomber as a replacement for the already obsolete Douglas TBD Devastator. The Navy placed an order for 286 of the aircraft in December 1940. The first flight of the XTBF-1 took place on 1 August 1941.

By December of that year, a second prototype had been accepted and in January 1942 the first production TBF-1 joined the fleet. During the first six months of 1942, 145 TBFs were delivered. Six of them were assigned to Torpedo Squadron (VT) 8 for evaluation. Missing the movement of the squadron aboard the carrier Hornet (CV-8), the six aircraft were ferried to Midway from Pearl Harbor in time to take part in the Midway battle. Operating from land, the aircraft attacked the Japanese fleet, but were mauled by enemy fighters. Five were shot down, and the surviving aircraft was badly damaged with one crew member dead and one wounded. The heavily damaged TBF-1 provided valuable information that would be the source of improvements to its combat survivability.

With ever increasing demands for aircraft as well as being faced with the Navy’s push for a replacement for the F4F Wildcat fighter, Grumman concentrated on the development of the XF6F Hellcat, farming out much of the production to General Motors’ newly-formed Eastern Aircraft Division. By war’s end, Eastern Aircraft’s plants had turned out 7,546 TBMs. By 1944 Grumman had produced 2,290 TBFs before production ended, bringing the total Avengers produced to 9,836 (2,882 TBM-1s and 4,664 TBM-3s). Great Britain and New Zealand received 921 of the aircraft. In keeping with their naming of torpedo planes for fish, the British named the TBF/TBM the “Tarpon.”

Increasingly effective anti-aircraft capabilities, combined with the vulnerable attack profile of a slow-flying torpedo bomber, rendered torpedo attacks rare after Midway. Thus Avengers were used in a variety of other roles, including reconnaissance, antisubmarine, light transport or cargo work, medical evacuation and close air support.

Please visit our “The Mystery of the Middle Seat” and “X Marks the Spot” blogs for more information on this aircraft.

Specs
Contractor
Grumman (TBM) General Motors (TBF)
Deployment Date
First flight August 7, 1941. Retired in the 1960s
Span
54 feet, 2 inches
Length
40 feet, 11.5 inches
Height
15 feet, 5 inches
Weight
10,545 lbs
Max. Speed
275 MPH
Service Ceiling
30,100 feet
Range
1,000 miles
Crew
3 (Pilot, gunner, plus radioman in fuselage station)
